Bikes > BMC > Fourstroke > Fourstroke R 01 One

  • BMC Fourstroke R 01 One

    Fourstroke R 01 One



    MSRP CHF 12999

    Derailleur
    SHIMANO Dura Ace Di2 (RD-R9250)
    Brakes
    SHIMANO XTR (BL-M9200 & BR-M9200)
    Frame
    Fourstroke R 01 | 01 Premium Carbon with Autodrop Technology | APS Suspension System | 120mm Travel | Fully Guided Internal Cable Routing | Post Mount Disc | 12 x 148mm Boost Thru-Axle
    Fork
    Öhlins RXC34 Carbon | 120mm Travel | DT Swisss Remote Lockout | 44mm offset
    Rims
    Duke Lucky Jack SLS5 | 28 Spokes | Inner Width 31mm (F), 28mm (R)
    • Frame Fourstroke R 01 | 01 Premium Carbon with Autodrop Technology | APS Suspension System | 120mm Travel | Fully Guided Internal Cable Routing | Post Mount Disc | 12 x 148mm Boost Thru-Axle
    • Size XL
    • Fork Öhlins RXC34 Carbon | 120mm Travel | DT Swisss Remote Lockout | 44mm offset
    • RearShock Öhlins TXC2 Air | 190 x 45mm | DT Swiss Remote Lockout
    • Gears 1 x 12
    • Cassette SHIMANO XTR (CS-M9200-12)
    • Chain SRAM GX Eagle Transmission Flattop (CN-TTYP-GX-A1)
    • Shifters SHIMANO XTR (SW-M9250-IR)
    • Brakes SHIMANO XTR (BL-M9200 & BR-M9200)
    • Handlebar ICS Carbon XC | One-Piece Full Carbon Cockpit | 760mm width | 3° Up sweep | 8° Back sweep | -19° Stem angle
    • Seatpost BMC Autodrop Integrated Dropper Seatpost | 80mm Drop
    • Seat Prologo Dimension NDR | Nack Carbon Rail | 143mm
    • Hubs Duke Badboy CL SP
    • Rims Duke Lucky Jack SLS5 | 28 Spokes | Inner Width 31mm (F), 28mm (R)
    • Tires Pirelli Scorpion XC RC | 2.4"
    Geometrie – fourstroke 01 XTR Di2
    Grösse S M L
    Stack mm 585 595 605
    Reach mm 412 434 456
    Sitzrohr st mm 420 460 510
    Oberrohr tt' mm 585 610 635
    Steuerrohr ht mm 90 100 110
    Sitzwinkel sa ° 73.5 73.5 73.5
    Steuerwinkel sa ° 70 70 70
    Kettenstrebe rc mm 445 445 445
    Front center fc mm 659 684 709
    Radstand wb mm 1101 1126 1151
    Tretlagerabsenkung mm 40 40 40
    Gabellänge fl mm 506 506 506
    Gabelvorlauf fr mm 51 51 51
    Nachlauf mm 80 80 80
    Kurbellänge mm 170 175 175
    Vorbaulänge mm 70 70 70
    Vorbauwinkel ° 6 6 6
    Lenkerbreite mm 720 720 720
    Lenkerhöhe mm 4 4 4
    Backsweep ° 9 9 9
    Sattelstützenlänge mm 350 400 400
    Überstandshöhe mm 759 791 820
